 |6-10kVA PL3 RM High Frequency Online UPS

High Frequency UPS
High Frequency UPS High Frequency UPS High Frequency UPS

6-10kVA PL3 RM High Frequency Online UPS

6kVA/ 10kVA rack mounted UPS, 208/220/230/240 VAC, 1:1

PL3 RM series power supply adopts online double conversion design and digital control technology and it features high input and output power factor, self-adaptive output frequency according to input frequency, intelligent battery management and excellent network management.

  • brand:

    EverExceed

  • Model:

    PL3 RM

  • Type:

    Rack mounted UPS，Single phase UPS

  • Rated voltage:

    208/ 220/230/240 VAC

  • Rated frequency:

    50/60Hz

  • Efficiency:

    Up to 98%

  • Applications:

    IDC( Internet Dater Center), network, servers and workstations, control system, communication system, office, PC etc.

  • Certificate:

    CE, TLC
inquiry now
  • Features
  • TECHNICAL DATA
  • SUCCESSFUL CASES
  • Download
  • Factory
  • Video
  • FAQ
                                                                                                                      Technical Features




High reliability

High scalability

High efficiency

Modular design, improves maintainability and reliability.

N+X redundancy, expanding as required saves initial investment.

Wide input voltage range and guarantees high efficiency operation with output power factor 0.9

Low TCO

Intelligent battery management

Zero conversion time

The products combines innovation, simplicity and low cost of ownership.
 The system intelligently control the whole process of charging & discharging, effectively improve the life time of the battery

UPS switches between the mains mode and battery mode without conversion time ensures reliability of the load operation




Battery cold start

Energy saving

Multi communication interface

It will add great value to your workflow by providing on-demand power
 ECO mode operation for energy saving

RS485, USB, SNMP, Relay card communications for network management and remote monitoring


Applications:

IDC( Inte rnet Dater Center), network，servers and workstations, control system, communication system，office，PC etc.




MODEL PL3 RM6KS PL3 RM6KL PL3 RM10KS PL3 RM10KL
Capacity 6kVA/6kW 10kVA/10kW
Phase 1 Phase in/1 Phase out
INPUT
Nominal Voltage 208/ 220/230/240VAC, L+N+PE
Input Voltage Range 110~300VAC
Input Frequency Range 50/60Hz±6Hz
Input Power Factor ≥0.99
Input Current Distortion (THDi) ≤4%(linear load); ≤5%(non-linear load)
Bypass Voltage Range -40%~20% of nominal voltage, adjustable
OUTPUT
Nominal Voltage 208/220/230/240VAC, L+N+PE
Voltage Regulation ±1%
Nominal Frequency 50/60Hz±0.1%
Output Frequency Line mode:50/60±1/2/3/4/5/6Hz, adjustable; Battery Mose:50/60±0.001 Hz
Output Power Factor 1
Output Voltage Distortion(THDu) ≤2% (linear Load); ≤5% (non-linear load)
Transfer Time Line mode to battery mode, 0ms
Crest Ratio 3:01
Overload Capacity
(Line Mode) 		102%~105% load,  30min;105%~125% load, 10min; 125%~150% load, 30s; >150% load, 500ms;
Overload Capacity
(Battery Mode)) 		102%~110% load,  10min; 105%~125% load, 1min
Overload Capacity
(Bypass Mode)) 		Depending the input breaker(63A)
Output Short Circuit Poretection Line Mode:Current limitation;Battery Mode: Current limitation:Bypass Mode: Breaker
BATTERY
Battery Type Sealed lead acid maintenance free(VRLA)
Nominal Voltage 192VDC/240VDC
Charging Voltage Floating Charge,2.25V/cell; Boost Charge, 2.35V/cell
Battery Number&Capacity 16 pcs, 12V/9Ah External 16 pcs, 12V/9Ah External
Charging Current 1~4A, adjustable, default 1 A 1-12A  1~4A,adjustable, default 1A 1-12A
Charging Mode Two Satges(CC/Floating) or Three Stages(CC/CV/Floating, adjustable)
Battery Protection Battery Leakage<500㎂, Over Voltage Protection, Under Voltage Protection,Over Current Protection;Battery Deep Discharge Protetion
EFFICIENCY
Line Mode 95.5%(Max)
Battery Mode 95%(Max)
ECO Mode 99%
INDICATORS
LCD Panel UPS status,Battery Level, Load Level, Input/Outpt/Battery Voltage, Fault&Alarm Code
Audible Alarm Utillty Failure, Battery Voltage Low, Overload, System Fault
MANAGEMENT
Interface Rs232/USB/SNMP card (optional)/ AS400 card(optional)/RS485 caed(optional)
Environment
Operation Temperature 0~40℃
Humidity 0~95%（non-condensing)
Noise ≤50dB @ 1 meter away
Stotage Temperature -15-60℃(Battery:0-40℃)
Altitude < 1000 m, derating 1% per 100m from 1000~2000m
Noise
(1 Meter Away) 		<55dB
Physical
Dimension(W*D*H) mm 440*753*173 440*487*86 440*753*173 440*487*86
Net Weight (kg) 58 11 62 12
Color Black(RAL9004)
STANDARDS
Safety IEC 62040-1:2017
EMC IEC 62040-1:2018
Performance IEC 62040-1:2011
Battery IEC 60896-22:2004



If you need to download files, you need to register as our member first ! log in / registered

  • PL3 RM Series High Frequency Online UPS (6~10kVA) V1.0 20241119.pdf
